HID multiCLASS RPK40 - RF proximity reader / SMART card reader - SIA 26-bit Wiegand

• Security
  64-bit authentication keys are extremely secure. Readers and cards require matching keys to function. All RF data transmission between the card and reader is encrypted, using a secure algorithm. The key management system reduces the risk of compromised data or duplicated cards.
• Elite custom keys
  Custom keys provide the highest level of security, where cards and readers are uniquely matched to individual sites or customers, and are non-interchangeable. Combining Elite custom keys with the Corporate 1000 can offer companies a scalable solution that can be implemented in facilities worldwide.
• Audiovisual indication
  Audio sounder provides various tone sequences to signify access granted, access denied, power up and diagnostics. Visually impaired cardholders can easily distinguish between access granted and access denied. A high-intensity light bar provides a clear visual status indication in red, green or amber, even in bright sunlight.
• Easily interfaced
  The reader's Wiegand output easily interfaces with most existing Wiegand protocol access control panels. The reader reads standard HID format data and will output data as encoded. When reading MIFARE cards, the reader can be configured to output 26-bit, 32-bit, 34-bit, 37-bit, 40-bit, or 56-bit Wiegand formats, based on the card serial number.
• Indoor/outdoor design
  Rugged, weatherized polycarbonate enclosure, designed to withstand harsh environments, provides reliable performance and resistance to vandalism. A tamper switch in reader housing facilitates the notification of a tamper alarm.

The multiCLASS family of card reader is designed for customers upgrading their current card system from the most popular proximity technologies to iCLASS credentials. With the RPK40 reader, the customer has the ability to transition to smart cards over time while incorporating the use of multiple card technologies within a single building or across multiple facilities.
The multiCLASS reader line provides enhanced security through mutual authentication and data encryption. HID, Indala and other popular proximity technologies are supported by multiCLASS. The RP40's and RPK40's designs allow project-specific formats and keys, and enables HID to support additional technologies as they become available.
Only the multiCLASS family of products provides true iCLASS security, the ease of proximity technology, the power of smart cards and the confidence of choosing HID, the worldwide leader in access control.

• Enable iCLASS, proximity or both technologies at the same time
• Multiple data outputs available when multi-technology card is presented depending on preference
• Configuration cards can configure the reader to custom installation requirements
• Same HID and Indala Proximity reader features and format compatibilities
• Ultra-low current consumption
• Larger voltage span
• Wiegand or clock-and-data outputs easily interface with existing access control panels
• The RPK40 combines a contactless card presentation with a personal identification number (PIN) to support dual factor authentication of identity
